Bluetooth 5.4 Adapter for PC USB Dongle Bluetooth Receiver for Speaker Wireless Mouse Keyboard Audio Transmitter
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
Drive-free 5.4 Bluetooth adapter
Product name: USB Bluetooth adapter;
Model: BR04;
Bluetooth version: 5.4 (BLE low power, low latency);
Transmission distance: 20 meters (barrier-free environment);
Support protocols: A2DP,HSP,AVRCP,HID,ACC, etc
5.4 Bluetooth dual-mode dual-channel, compatible with Bluetooth 2.0, 3.0, 4.0, 5.0, 5.1 and 5.3 specifications;
Intelligent low power chip, RF transceiver, provides low latency flexible and powerful Bluetooth applications;
Support Cass2 Power level 20 meters away (in open environment);
Support Bluetooth 5.4 dual-mode specifications (LMP 13.X true Bluetooth 5.4 standard);
Support USB2.0/3.0 interface;
Supports simultaneous connection of multiple devices (up to 7 devices can be connected);
Operating temperature -20 to 70℃;
Supported operating system: Windows 8.1, 10, 11 (no driver, plug and play);
Supported protocol :HFP/HSP(hands-free phone/headset)A2DP/ AVRCP(stereo music)HID/HOGP(keyboard and mouse)/ACC. Android smartphones, etc.
General Specification:
Bluetooth Specification | |||
Standard | Bluetooth V5.4 | ||
Profiles | Bluetooth low energy Dual-mode Bluetooth | ||
Frequency Band | 2.402G-2.480G | ||
Sensitivity | -86dBm@.01%BER | ||
RF TX Power | +6dBm(ClassП) | ||
Power | |||
Supply Voltage | 5V DC(MAX5.75V) | ||
Working Current | Depends on profiles, 22mA typical |
| |
Standby Current (Connected ) | 0.4uA |
| |
Operating Environment |
| ||
Temperature | -20℃ to +70℃ |
| |
Humidity | 10%-90% Non- Condensing |
| |
Environmental RoHS Compliant |
Data sheet
