HUANANZHI X99 TF LGA 2011-3 XEON X99 Motherboard support Intel E5 2666 2678 2696 v3 v4 DDR3 DDR4 RECC NON-ECC memory NVME

Specifications:

Model：HUANANZHI TF Motherboard

CPU Socket：Support Intel® 2011-3 Processors

Main chipset: C612 ... Etc chipset shipped randomly

Ｍemory Socket：4*DDR3 Memory,4*DDR4 Memory，(when use DDR3 memory support Intel® Xeon 2678V3/2676V3/2673V3/2629V3/2649V3/2669V3/2696V3)，Maximum Memory Capacity 4*32G

Ｍemory Standard：Support Dual channel DDR3 1866/1600/1333MHz，DDR4 2400/2133/1866MHz

SATA Inderface：6*SATA3.0 interface，2*SSATA3.0 interface

Extended Inderface：IO：1*PS/2 Mouse / keyboard interface，4*USB2.0，4*USB3.0，1*Gigabit Ethernet Card，6*3.5MM Audio interface；1*Digital audio nterfac，Expansion pin：2*9pin USB2.0，1*19pin USB3.0，1*Front audio output pin

Expansion Slots：2*PCI Express3.0X16，2*PCI ExpressX1，1*PCI ExpressX4，2*M.2 NVME，1*M.2 WIFI

Soud Track：7.1

Network interface：Gigabit Ethernet

Power interface：24pin+8pin

Fan interface：4

PCB layer：10 layer PCB，6Phases power supply

Dimension：300*244MM ATX

Motherboard does not support RGB
